KEEWAY RKV125 User Manual

Valve clearance
Intake
0.03-0.05
＿
12.2 Fault Diagnosis
Low compression pressure Noisy cylinder head
Improperly adjusted valve clearance Improperly-adjusted valve clearance
Valve burnt or bent Valve spring hurt
Poorly sealed valve race Too high compression pressure
Air leakage at cylinder head Too much carbon deposited in the combustion chamber
Improperly installed spark plug
12.3 Cylinder Head
12.3.1 Removal
Screw off the ten locknuts and remove cylinder cover.
Remove cylinder cover hood.
Screw off two locknuts and remove the rocker arm, return spring
and rocker arm shaft.
Cylinder cover
Bolt
Cylinder cover hood
Rocker arm
Bolt
Return spring
Rocker arm shaft

KEEWAY RKV125 Specifications

General

Engine Type	Single cylinder, 4-stroke, air-cooled
Fuel System	Carburetor
Transmission	5-speed
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Cooling System	Air-cooled
Seat Height	770 mm
Weight	135 kg
Fuel Tank Capacity	17 L
Rear Suspension	Dual shock absorbers
