VIII Rear Wheel/Rear Suspension
Preparatory data----------------------------------- 8.1
Fault diagnosis-------------------------------------8.2
Rear wheel------------------------------------------8.3
Rear shock absorber/rear swing arm----------- 8.4
Chain drive assembly-----------------------------8.5
8.1 Preparatory Data
Precautions on operation
Do not contaminate braking shoe ad brake disc with oil.
Basic preparatory data
Item
Standard
Value（mm）
Service
Limit
（mm）
Rear
wheel
Shimmy
Longitudinal
2.0
Transversal
2.0
Tightening torque
Rear shat locknut 85 - 98 N·m
Rear shock absorber top nut 37 - 44 N·m
Rear shock absorber bottom nut 37 - 44 N·m
8.2 Fault Diagnosis
8.2.1 Shimmy Rear Wheel
Distorted wheel rim
Worn rear bearing
Troubled tyre
