10.3 Oil Pump
10.3.1 Removal
Remove right cover. Take down the engine oil filter and release
oil pump mounting screw.
Take down oil pump block, drive gear and pump shaft.
Screw off the screw
Take down pump seat.
Remove the screw and take down pump cover.
Disassemble oil pump.
Check radial clearance between inner rotors
Allowable limit: 0.2mm.
Oil pump block
Testing gauge
Screw
Oil Pump
Screw
Oil Pump
Oil pump gear
