Bent or injured gearshift plate Abnormal engine oil and oil level
14.3 Clutch
14.3.1 Removal
Screw off the four bolts for separating plate in criss-cross mode.
Remove release lever, sleeve, bearing, separating plate and clutch
spring.
Removed components refer to exploded view.
Use a special tool to screw off clutch locknut.
Remove locknut and washer.
Remove clutch center bracket.
Remove clutch drive and driven friction plates.
Remove clutch pressure plate.
Removed components refer to exploded view.
Remove spline washer.
Remove housing assembly.
Install clutch in the reverse order of removal.
Four-pawl bush
wrench
Universal fixer
Housing assembly

KEEWAY RKV125 Specifications

General

Engine Type	Single cylinder, 4-stroke, air-cooled
Fuel System	Carburetor
Transmission	5-speed
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Cooling System	Air-cooled
Seat Height	770 mm
Weight	135 kg
Fuel Tank Capacity	17 L
Rear Suspension	Dual shock absorbers
