Measure rocker arm shaft OD.
Allowable limit: 11.95mm.
Measure rocker arm hole ID.
Allowable limit: 12.05mm.
Clearance between rocker arm and rocker arm shaft
Allowable limit: 0.08mm.
Screw off the two locknuts and remove the lock washer, cam
shaft and C-type gasket. Screw off the three cap nuts and
hexagon nuts, remove cylinder head.
Micrometer
Tester
Cylinder head
Lock washer
C-type gasket
Bolt

KEEWAY RKV125 Specifications

General

Engine Type	Single cylinder, 4-stroke, air-cooled
Fuel System	Carburetor
Transmission	5-speed
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Cooling System	Air-cooled
Seat Height	770 mm
Weight	135 kg
Fuel Tank Capacity	17 L
Rear Suspension	Dual shock absorbers
