Keithley 2182

14-8 SCPI Reference Tables
Command Description
Default
Parameter Ref
SCPI
:REFerence? Query Rel value. √
:LPASs Control analog filter for DCV1: Sec 3
[:STATe] <b> Enable or disable analog filter. OFF
[:STATe]? Query state of analog filter.
:DFILter Configure and control digital filter: Sec 3
:WINDow <n> Specify filter window (in %); 0 to 10. 0.01
:WINDow? Query filter window.
:COUNt <n> Specify filter count; 1 to 100. 10
:COUNt? Query filter count.
:TCONtrol <name> Select filter type; MOVing or REPeat. MOVing
:TCONtrol? Query filter type.
[:STATe] <b> Enable or disable digital filter. ON
[:STATe]? Query state of digital filter.
:CHANnel2 Channel 2 voltage commands: OFF
:LQMode <b> Enable or disable low charge-injection mode. Sec 2
:LQMode? Query state of low charge-injection mode.
:RANGe Configure channel 2 measurement range: Sec 3 √
[:UPPer] <n> Select range; 0 to 12 (volts). 12 √
[:UPPer]? Query range value. √
:AUTO <b> Enable or disable autorange. ON √
:AUTO? Query state of autorange. √
:REFerence <n> Specify reference (Rel) value for Channel 2;
–12 to 12 (volts).
0 Sec 4 √
:STATe <b> Enable or disable Rel. ON √
:STATe? Query state of Rel. √
:ACQuire Use the voltage on Channel 2 as Rel.
:REFerence? Query Rel value. √
:LPASs Control analog filter for DCV2: Sec 3
[:STATe] <b> Enable or disable analog filter. OFF
[:STATe]? Query state of analog filter.
:DFILter Configure and control digital filter: Sec 3
:WINDow <n> Specify filter window (in %); 0 to 10. 0.01
:WINDow? Query filter window.
:COUNt <n> Specify filter count; 1 to 100. 10
:COUNt? Query filter count.
:TCONtrol <name> Select filter type; MOVing or REPeat. MOVing
:TCONtrol? Query filter type.
[:STATe] <b> Enable or disable digital filter. ON
[:STATe]? Query state of digital filter.
Table 14-7
SENSe command summary (cont.)
