Keithley 2303 User Manual

1-10 Getting Started
Setups — Save, Power-on, and Recall
Setups are configured by SAVE SETUP, POWER ON SETUP and RECALL SETUP items
of the MENU (which is accessed by pressing the MENU key).
NOTE Table 1-2 shows the menu structure. Rules to navigate the menu follow the table.
The setup MENU items are explained as follows:
•
SAVE SETUP - Save the present power supply setup to a memory location;
SAV0-SAV4.
•
RECALL SETUP - Return the power supply to the RST defaults (Table 1-1), or to one
of the user saved setups; SAV0-SAV4. Note the operate state (output) is always recalled
as OFF.
•
POWER-ON SETUP - Select the setup to use at power-up; RST, SAV0-SAV4 (output
off) or SAV5-SAV9 (output on or off). Note that SAV5-SAV9 are not available for the
Model 2303-PJ.
When powering up to the SAV0, SAV1, SAV2, SAV3, or SAV4 setup, the output will be off
regardless of the operate state when the setup was saved. For example, if the output is on when
the setup is saved as SAV0, the power supply will power up with the output off for the SAV0
power-on setup.
Average time 33 µsec
Average readings 1
Trigger delay 0.00000 sec
Trigger level:
Models 2303 and 2303B
Model 2303-PJ:
5A range
500mA range
0.000A
0.000A
0.0000A
Long integration:
Integration time 1 second
Pulse timeout 16 seconds
Trigger edge Rising
Trigger level:
Models 2303 and 2303B
Model 2303-PJ:
5A range
500mA range
0.000A
0.000A
0.0000A
Table 1-1 (cont.)
Factory defaults (RST)
Setting RST default
