Keithley 2303 User Manual

11-4 SCPI Tables
Table 11-4
SENSe command summary
Command Description
Default
parameter
SCPI
:SENSe[1]
:FUNCtion <name>
:FUNCtion?
:NPLCycles <n>
:NPLCycles?
:AVERage <NRf>
:AVERage?
:CURRent [:DC]
:RANGe
[:UPPer] <n>
[:UPPer]?
:AUTO <b>
:AUTO?
:PCURrent
:AVERage <NRf>
:AVERage?
:MODE <name>
:MODE?
:TIME
:AUTO
:HIGH <NRf>
:HIGH?
:LOW <NRf>
:LOW?
:AVERage <NRf>
:AVERage?
:SYNChronize
[:STATe] <b>
[:STATe]?
:DELay <NRf>
:DELay?
:TLEVel <NRf>
Select measurement function (“VOLTage,” “CURRent,”
“PCURrent,” “LINTegration,” or “DVMeter”).
Query measurement function.
Specify integration rate (in line cycles) for voltage, cur-
rent, and DVM measurements (0.01 to 10).
Query integration rate.
Specify the average count for voltage, current, and DVM
measurements (1 to 10).
Query average count.
Path to configure the current measurement function:
Current measurement range:
Measurement range — specify expected current
(0 to 5 amps).
Query current measurement range.
Enable or disable auto range.
Query state of auto range.
Path to configure the pulse-current measurement function:
Specify the average count for pulse-current measurements;
measurements; 1 to 100 or 1 to 5000 (pulse current
digitization).
Query average count.
Select pulse-current measurement mode (HIGH,
LOW, or AVERage).
Query pulse-current measurement mode.
Path to set pulse-current integration times:
Power supply sets integration times.
Specify integration time (in sec) for high pulse
measurements (33.33E-06 to 0.8333).
Query high integration time.
Specify integration time (in sec) for low pulse
measurements (33.33E-06 to 0.8333).
Query low integration time.
Specify integration time (in sec) for average pulse
measurements (33.33E-06 to 0.8333).
Query average integration time.
Path for pulse detection triggering:
Send ON to select pulse current measurements, or
OFF to select pulse current digitization.
Query pulse current synchronization selection.
Specify trigger delay in seconds; 0 to 0.1 or 0 to 5
(pulse current digitization).
Query trigger delay.
Models 2303 and 2303B— Set trigger level: 0 to 5 (amps).
VOLT
1
1
5.0
OFF
1
HIGH
3.333E-05
3.333E-05
3.333E-05
ON
0
0
√
√
√
√
√
√
√
