Keithley 2303 User Manual

11-6 SCPI Tables
Table 11-5
SOURce command summary
Command Description
Default
parameter
SCPI
[:SOURce]
:VOLTage Path to set output voltage: √
[:LEVel] √
[:IMMediate]
[:AMPLitude] <n> Specify voltage amplitude in volts: 0 to 15 (1mV resolution). 0.0 √
[:AMPLitude]? Query voltage amplitude. √
:CURRent Path to configure current: √
[:LIMit] Path to configure current limit:
[:VALue] <NRf> Specify current limit value in amps: 0 to 5 (100µA resolution). 0.25
[:VALue]?
Query current limit value.
:TYPE <name> Select current limit type (LIMit, TRIP, LIM
:TYPE? Query current limit type.
:STATe?
Query state of current limit: 1 = in current limit (for
LIMit type) or output tripped (for TRIP type);
0= not in LIMit/TRIP.
LIMRELAY|LIMITRELAY, or TRIPRELAY).*
*LIMRELAY (LIMIT RELAY) and TRIPRELAY are available in Models 2303/2303B with firmware revision A06 and higher.
