5-54 Delta, Pulse Delta, and Differential Conductance Model 6220/6221 Reference Manual
Return to Section 5 topics
Measurement units
The fundamental measurement for Differential Conductance is differential voltage
(dV). However, the dV reading can be converted into a differential conductance
(dG), differential resistance (dR) or power (Watts) reading. See page 5-16 for
details on selecting “Measurement units”.
With Ohms (dR) or Siemens (dG) measurement units selected, the reading is cal-
culated as follows:
dR = dV/dI
dG = dI/dV
With Power measurement units selected, power is calculated using Average Volt-
age and Average Current and is explained in the following paragraphs.
Average Voltage and Power
Average Voltage calculation
Average Voltage is the average bias voltage that was present across the device
when the corresponding Differential Conductance reading was taken. For remote
operation, the Average Voltage reading for Differential Conductance will be
included in the returned data string when the AVOLtage data element is selected.
See “FORMat subsystem,” on page 13-4 for details on selecting data elements.
Average Voltage is calculated as follows:
Where: AvgVolt is the Average Voltage corresponding to a given Differential
Voltage (dV) reading.
X, Y and Z are the three A/D measurements for the dV reading.
Power calculation
With WATTS (power) measurement units selected, power for Differential Conduc-
tance is calculated using Average Voltage (see “Average Voltage calculation”
above) and Average Current.
AvgVolt
XY+()
2
-------------------
ZY+()
2
------------------+
2
---------------------------------------------=
AvgVolt
X2YZ++
4
----------------------------=
