17-10 Calibration Model 6220/6221 Reference Manual
Return to Section 17 topics
9. Press ENTER. The display will prompt:
-20V COMPLIANCE CAL
Press ENTER to Output -2.0000mA
10. Press ENTER to output -2mA for -20V compliance calibration. The instru-
ment will prompt as follows:
DMM RDG=-020.0000V
Use , , , , ENTER, or EXIT
11. Note the DMM reading, then adjust the Model 6220/6221 display to agree
with that value.
12. Press ENTER. The display will prompt:
-.1V COMPLIANCE CAL
Press ENTER to Output -2.0000mA
13. Press ENTER to output -2mA for -0.1V compliance calibration. The instru-
ment will prompt as follows:
DMM RDG=-0.100000V
Use , , , , ENTER, or EXIT
14. Note the DMM reading, then adjust the Model 6220/6221 display to agree
with that value.
15. Press ENTER. The display will prompt:
100V COMPLIANCE CAL
Press ENTER to Output +2.0000mA
16. Press ENTER to output +2mA for 100V compliance calibration. The instru-
ment will prompt as follows:
DMM RDG=+100.0000V
Use , , , , ENTER, or EXIT
17. Note the DMM reading, then adjust the Model 6220/6221 display to agree
with that value.
18. Press ENTER. The display will prompt:
21V COMPLIANCE CAL
Press ENTER to Output +2.0000mA
19. Press ENTER to output +2mA for 21V compliance calibration. The instru-
ment will prompt as follows:
DMM RDG=+21.00000V
Use , , , , ENTER, or EXIT
20. Note the DMM reading, then adjust the Model 6220/6221 display to agree
with that value.
21. Press ENTER. The display will prompt:
-100V COMPLIANCE CAL
Press ENTER to Output -2.0000mA
