Digital I/O, Analog Outputs, and External Feedback 11-17

SCPI programming — external feedback

Programming example — external feedback

The following command sequence conﬁgures Model 6514 to perform measurements using

the external feedback mode:

SYST:ZCH ON ‘ Enable zero check.

VOLT:XFE ON ‘ Enable external feedback.

FUNC ‘VOLT’ ‘ Select Volts function.

SYST:ZCH OFF ‘ Disable zero check.

READ? ‘ Trigger measurement(s) and request

reading(s).

Table 11-4

SCPI commands — external feedback

Commands Description Ref Default

[SENSe] SENSe Subsystem:

:VOLTage Volts conﬁguration:

:XFEedback <b> Enable or disable external feedback. Off

:FUNCtion VOLTage Select Volts function. Sec 3

SYSTem SYSTem Subsystem:

:ZCHeck <b> Enable or disable zero check. Sec 2 On
