Keithley 6514

4
Amps Measurements
• Measurement overview — Summarizes the current measurement capabilities of Model
6514.
• Amps measurement procedure — Provides the procedure to measure amps.
• High-Impedance measurement techniques — Explains non-driven guarding tech-
niques to eliminate leakage currents in high-impedance test circuits.
• SCPI programming — Covers the basic SCPI commands used for the amps function.
• Amps measurement considerations — Covers measurement considerations that apply
to amps measurements.
• Applications — Covers applications to measure diode leakage current, capacitor leak-
age current, cable insulation resistance, and surface insulation resistance.
