Keithley 6514 User Manual

13-16 Status Structure
The commands to read the condition registers are listed in Table 13-4. For details on reading
registers, see “Reading registers”.
Event registers
As Figure 13-1 shows, each status register set has an event register. When an event occurs,
the appropriate event register bit sets to 1. The bit remains latched to 1 until the register is reset.
Reading an event register clears the bits of that register. *CLS resets all four event registers.
The commands to read the event registers are listed in Table 13-5. For details on reading reg-
isters, see “Reading registers”.
Table 13-4
Common and SCPI commands — condition registers
Command Description
STATus STATus subsystem:
:OPERation:CONDition? Read operation condition register.
:MEASurement:CONDition? Read measurement condition register.
:QUEStionable:CONDition? Read questionable condition register.
Table 13-5
Common and SCPI commands — event registers
Command Description
*ESR? Read standard event status register.
STATus STATus subsystem:
:OPERation:[:EVENt]? Read operation event register.
:MEASurement:[:EVENt]? Read measurement event register.
:QUEStionable:[:EVENt]? Read questionable event register.
Note: Power-up and *CLS resets all bits of all event registers to 0. STATus:PRESet has no
effect.
