Getting Started 1-9
6 IEEE-488
Connector for IEEE-488 (GPIB) operation. Use a shielded cable, such as Models 7007-1 and 7007-2.
7 DIGITAL I/O
Male DB-9 connector for digital output lines and component handler signals.
8 TRIGGER LINK
Eight-pin micro-DIN connector for sending and receiving trigger pulses among connected instru-
ments. Use a trigger link cable or adapter, such as Models 8501-1, 8501-2, 8502 and 8503.
9 RS-232
Female DB-9 connector for RS-232 operation. Use a straight-through (not null modem) DB-9 shielded
cable.
10 Power module
Contains the AC line receptacle, power line fuse, and line voltage setting. The instrument can be con-
figured for line voltages of 100V/120V/220V/240VAC at line frequencies of 50 or 60Hz.
