1-14 Getting Started
Setting Factory GPIB
Limit Tests:
Limit 1 and Limit 2: Disabled Disabled
HI and LO Values 1, -1 1, -1
Digital Fail Output Patterns 15 15
Digital Output Pass Pattern 15 15
Auto-Clear Off Off
Delay 0.00010 sec 0.00010 sec
Output Clear Pattern 15 15
Line 4 Mode End of Test End of Test
Median Filter: Off Off
Rank 1 1
MX+B: Disabled Disabled
“M” Value 1.0 1.0
“B” Value 0.0 0.0
Units MXB MXB
Percent: Disabled Disabled
Reference 1.0 1.0
Range 20V Auto
Rate: Slow Slow
NPLC 6.0 (60Hz) or 5.0 (50Hz) 6.0 (60Hz) or 5.0 (50Hz)
Rel: Off Off
Rel Value (VAL) 0.0 0.0
RS-232: No effect (Off at factory) No effect (Off at factory)
All Settings No effect No effect
Trigger Layer (CONF-TRIG):
Trig-In Source Event IMM IMM
Trigger Count 1 1
Trigger Delay 0 0
Input Trigger Link Line 1 1
Source Bypass NEVER NEVER
Output Trigger Link Line 2 2
Units No effect No effect
V-Drop Disabled Disabled
Zero Check Enabled Enabled
Zero Correct Disabled Disabled
Table 1-2 (cont.)
Default settings
