ion 10: Pre-scan monitor DAQ6510 Data Acquisition / Multimeter System
User's Manual
10-4 DAQ6510-900-01Rev. A / April 2018
Using SCPI commands
This sequence of SCPI commands executes a scan once the the environment reaches a target
temperature.
You may need to make changes so that this code will run in your programming environment. In the
table, the SCPI commands have a light gray background.
Send the following SCPI commands for this example application:
Commands Descriptions
*RST
 Put the instrument in a known state
FUNC "TEMP", (@101)
 Monitor temperature on channel 101
TEMP:TRAN TC, (@101)
 Set transducer type to thermocouple
TEMP:TC:TYPE K, (@101)
 Set thermocouple type to K
TEMP:UNIT CELS, (@101)
 Set unit to Celsius
TEMP:TC:RJUN:RSEL INT, (@101)
 Set internal reference
ROUT:SCAN:MON:CHAN (@101)
 Monitor channel 101
ROUT:SCAN:MON:LIM:UPP 30
 Set upper limit to 30 Celsius degree
ROUT:SCAN:MON:MODE UPP
 Set monitor mode to upper
FUNC "RES", (@102:105)
 Scan resistance on channel 102 through 105
RES:RANG:AUTO ON, (@102:105)
 Set auto range
ROUT:SCAN:CREATE (@101:105)
 Scan channel 101 through 105
ROUT:SCAN:COUN:SCAN 10
 Set scan count to 10
INIT
 Initiates the monitoring of channel 101 conditions, which
will enable the scan when it crosses the temperature
threshold
