Keithley DAQ6510 User Manual

In this section:
Additional DAQ6510 information ............................................ 12-1
Additional DAQ6510 information
This manual has prepared you to start using your new DAQ6510 Data Acquisition / Multimeter
System for your application. For more detailed information, refer to the Keithley Instruments
DAQ6510 Reference Manual.
Also see tek.com/keithley for support and additional information about the instrument. From the
website, you can access:
• The Knowledge Center, which contains the following handbooks:
 The Low Level Measurements Handbook: Precision DC Current, Voltage, and Resistance
Measurements
 Switching Handbook: A Guide to Signal Switching in Automated Test Systems
• Application notes
• Updated drivers
• Information about related products
Your local Field Applications Engineer can help you with product selection, configuration, and usage.
Check the website for contact information.
Section 12
Next steps

Keithley DAQ6510 Specifications

General

Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Frequency, Temperature, Capacitance
Frequency Range	3 Hz to 300 kHz
Temperature Range	-200°C to 1820°C
Connectivity	USB, Ethernet, GPIB
Digit Display	6.5 digits
Channels	Up to 80 channels
Memory	Internal non-volatile memory for data storage
Power Supply	100 V to 240 V, 50 Hz to 60 Hz
Dimensions	213 mm x 297 mm x 88 mm (8.4 in x 11.7 in x 3.5 in)
Weight	3.6 kg
