Keithley DAQ6510 User Manual

Section
7: Scanning resistors using 4W measurement DAQ6510 Data Acquisition / Multimeter System
User's Manual
7-6 DAQ6510-900-01Rev. A / April 2018
Using SCPI commands
This sequence of SCPI commands executes a 4-wire resistance scan.
You may need to make changes so that this code will run in your programming environment.
Send the following commands for this example application:
Commands Descriptions
*RST
 Reset the DAQ6510
ROUT:SCAN:COUN:SCAN scanCnt
 Set the number of times the scan is repeated
FUNC 'FRES',(@101:106)
 Set function to 4-wire measurement
FRES:OCOM ON, (@101:106)
 Set offset compensation to "on"
FRES:RANG 100, (@101,102)
 Set the fixed range at 100 Ω
FRES:RANG 10, (@103,104)
 Set the fixed range at 10 Ω
FRES:RANG 1, (@105,106)
 Set the fixed range at 1 Ω
ROUT:SCAN:CRE (@101:106)
 Set the scan list
TRAC:CLE
 Clear the reading buffer
INIT
 Initiate the scan
*WAI
 Wait for scan completion

Keithley DAQ6510 Specifications

General

Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Frequency, Temperature, Capacitance
Frequency Range	3 Hz to 300 kHz
Temperature Range	-200°C to 1820°C
Connectivity	USB, Ethernet, GPIB
Digit Display	6.5 digits
Channels	Up to 80 channels
Memory	Internal non-volatile memory for data storage
Power Supply	100 V to 240 V, 50 Hz to 60 Hz
Dimensions	213 mm x 297 mm x 88 mm (8.4 in x 11.7 in x 3.5 in)
Weight	3.6 kg
