E8257D/67D, E8663D PSG Signal Generators Service Guide 195
Replaceable Parts
Assemblies
B1 Fan 3160–4121 2-198,
2-199,
2-200, and
2-206
3160–4121 2-201,
2-202, and
2-207
RF Output Connector (1.85 mm)
(Option 567)
5065–9852 2-240 N/A
RF Output Connector (2.4 mm)
(Options 532, 540, 544, and 550)
5063–1700 2-241 5063-1700 2-241
RF Output Connector (3.5 mm)
(Options 513 and 520)
08673-60040 2-242 08673–60040 2-242
RF Output Connector (Type–N)
(E8663D and Option 520)
1250-3968 08559–60002 2-243
a. Requires firmware version C.06.00 or greater.
b. Requires firmware version C.06.17.
- Send SERV:REPL:FRAC command if E8251-60647 rev. is A0100 or A0101.
c. Requires firmware version C.04.17 or greater.
d. Requires firmware version C.04.53 or greater.
e. Requires the temperature compensation resistor pack on A25B to be installed.
f. Requires firmware version C.05.31 or greater.
Table 2-3
Assembly E8257D and E8663D E8267D
Part Number Page Number Part Number Page Number
