Setting Up the Oscilloscope 1
Infiniium Z-Series Oscilloscopes User’s Guide 13
Environmental Characteristics
Table 2 Z-Series Oscilloscope Environmental Characteristics
Environment Indoor use only.
Ambient Temperature Operating: 5 °C to + 40 °C
Non-operating: –40°C to +65 °C
Humidity Operating: up to 95% relative humidity (non-condensing) at +40 °C
Non-operating: up to 90% relative humidity at +65 °C
Altitude Operating: up to 4,000 meters (12,000 feet)
Non-operating: up to 15,300 meters (50,000 feet)
Installation/ Measurement
Category
Installation category: 2
Measurement category: 1
Weight 71 lbs
Dimensions 20 in. wide (50.8 cm), 13.3 in. tall (33.8 cm), and 19.4 in. deep (49.3
cm)
Safety CAN/CSA-C22.2 No. 61010-1-04
UL Std. No. 61010-1 (2nd Edition)
Voltage Fluctuations Note that the main supply voltage fluctuations are not to exceed
±10% of the nominal supply voltage.
Pollution Degree The Infiniium Z-Series oscilloscopes may be operated in
environments of Pollution Degree 2.
Pollution Degree
Definitions
Pollution Degree 1: No pollution or only dry, non-conductive pollution occurs.
The pollution has no influence. Example: A clean room or climate controlled
office environment.
Pollution Degree 2. Normally only dry non-conductive pollution occurs.
Occasionally a temporary conductivity caused by condensation may occur.
Example: General indoor environment.
Pollution Degree 3: Conductive pollution occurs, or dry, non-conductive
pollution occurs which becomes conductive due to condensation which is
expected. Example: Sheltered outdoor environment.
