16 Infiniium Z-Series Oscilloscopes User’s Guide
1 Setting Up the Oscilloscope
Connecting Power
1 Connect the power cord to the rear of the oscilloscope, then to a suitable AC
voltage source.
Table 3 Power Requirements
Power 100 - 240 VAC ±10% at 50/60 Hz
Maximum input power: 1350 Watts
Well-regulated power is required for 100-120 VAC operation
Use Supplied Power Cord
Use only power cords designed for your oscilloscope.
The power cord provided is matched to the country of origin of the order.
Properly Ground the Oscilloscope
To avoid electric shock, be sure the oscilloscope is properly grounded.
Note that the oscilloscope’s power supply has a built-in safety feature that, after the
oscilloscope is turned off, requires the oscilloscope to remain off for about 10 seconds before
it is turned back on.
