1 Getting Started
16 Keysight 2050/60 X-Series User’s Guide
Figure 1-1 USB sensor
LED indicator
Indicates the USB sensor state.
Refer to “LED Indicator Sequence During Power-Up for the USB Sensor”
on page 42 for more information.
RF input port for
RF/microwave signals
USB cable
Physical secure lock mechanism
USB port
External trigger ports
