1 Getting Started
34 Keysight 2050/60 X-Series User’s Guide
Figure 1-18 Auto-locate a LAN instrument in Keysight Connection Expert via Static IP
7 Click Interactive IO to verify the LAN sensor is connected.
8 When the LAN sensor is connected, go to Chapter 2, "Using the 2050/60 X-Series with
the Keysight BenchVue" to launch the BenchVue, or proceed to operate the LAN sensor
via remote programming.
Alternatively, you can locate the LAN sensor by entering its default static IP address
(192.168.0.10) in the Add a LAN device (Add > LAN instrument) window.
To revert to the Dynamic IP mode from the static IP mode, you can either:
– send the following SCPI commands.
– SYSTem:COMMunicate:LAN:DHCP[:STATe] 1
– SYSTem:COMMunicate:LAN:AIP[:STATe] 1
– SYSTem:COMMunicate:LAN:RESTart
– configure and renew the LAN settings via the instrument web browser.
Refer to “Dynamic IP mode” on page 24 for the procedure. You will need to power cycle the
LAN sensor for the new network settings to take effect.
