Keysight U2057XA - Multiple Bench Operation; Figure 2-28 Multiple Bench Display Example; Multiple Bench Display Example

2 General Operating Information
68 Keysight 2050/60 X-Series User’s Guide
Multiple bench operation
Figure 2-28 Multiple bench display example
Sensor number
Set the sensor bench view layout
Corresponds
with respective
sensor number
Double-click each connected sensor icon to open its related bench
application window
