Getting Started 1
Keysight 2050/60 X-Series User’s Guide 39
Configuring the LAN remotely using SCPI commands
You can send SCPI commands to automatically or manually configure the LAN settings for
the LAN sensor. Refer to the 2050/60 X-Series Programming Guide for details.
Mount the L2065XT/66XT/67XT
The L2065XT/66XT/67XT is strongly recommended to be mounted on a cooling plate for
more effective heat dissipation when used in a TVAC chamber.
The cooling plate consists of four mounting threaded holes and the minimum thread height
of each hole is 6 mm.
Mounting dimensions
Figure 1-26 L2065XT/66XT/67XT mounting dimensions
36.00 mm
90.00 mm
40.00 mm
60.50 mm
136.00 mm
24.00 mm
