Installation
P/N 06-236716-001 2-1 August 2007
CHAPTER 2
INSTALLATION
2-1 INSTALLATION MATERIALS
2-1.1 Materials Provided
Check and ensure that the received shipment of the Kidde AEGIS™ unit consists of:
The Hardware Kit contains the following:
2-1.2 Materials Required
The materials listed below are not supplied with the system, but are required for installation.
• No. 10 or 3/16-inch mounting hardware
Table 2-1. Kidde AEGIS Control Unit Contents
Description Part Number Quantity
Enclosure Assembly (with door) 06-220132-001 1
Power Supply Unit 06-118394-001 1
Printed Circuit Board (PCB) 06-220113-001 1
Bezel Assembly 06-220114-001 1
Hardware Kit 06-220147-001 1
Installation/Configuration Kit 06-220148-002 1
Operating Instructions 06-236719-002 1
Keys (in poly bag) 06-250319-013 1
Table 2-2. Hardware Kit Contents (P/N 06-220147-001)
Description Quantity
Ground Wire Assembly (Power Supply Unit Enclosure) 1
Power Supply Unit Wiring Harness 1
Battery Harness (2 long jumpers, 1 in-line fuse holder) 1
AC Safety Cover/Warning Label 1
3/4-inch Nylon Spacer 1
Nylon Pan Head Screw (8-32 x 1-1/4) 1
Threaded Aluminum Standoff (8-32 x 2-3/8) 8
INT Sems Screw (8-32 x 5/16) 8
Power Supply Unit Rentention Screw (M3 x 5) 1
End of Line Resistor Assembly (5.1K) 10
1/4-inch x 1-1/4-inch 10A Time Delay Fuse
Cooper Bussman MDA-10-R
1
