List of Agency Listed Compatible Devices
August 2007 B-2 P/N 06-236716-001
* Must be used in conjunction with Microswitch P/N 87-120039-001 for momentary operation.
Table B-3. Initiator-Based Releasing Devices
* The maximum circuit resistance for this device must be 10 ohms, regardless of the number used. The firing current will be
2.5 Amps.
Table B-2. Releasing Solenoid
Wire Length (ft.)
Device
I
(Min.)
Amps
Resistance
(Max.)
Ohms
On Time
12
AWG
14
AWG
16
AWG
18
AWG
Max.
Number per
Circuits
Agency
890181 2.4 10 Momentary 300 200 120 — 1 or 2 UL, FM
895630 2.0 12 Momentary 300 200 120 — 1 or 2 UL, FM
899175 2.20 10.8 Momentary 300 200 120 — 1 or 2 UL, FM
48650001 0.24 103 Steady 3000 2000 1200 800 1 or 2 UL, FM
06-118329-001 0.225 108 Steady 3000 2000 1200 800 1 or 2 FM
06-118384-001 0.52 46 Steady 1440 760 480 340 1 or 2 UL
38-509834-001 0.632 38 Steady 1050 550 330 240 1 or 2 UL, FM
38-509837-001 0.4 60 Steady 2300 1460 915 570 1 or 2 UL, FM
81-100000-001 0.44 59 Steady 2300 1460 915 570 1 or 2 UL, FM
87-120099-001* 2 12 Momentary 360 240 140 — 1 or 2 UL, FM
60-120099-001* 2 12 Momentary 360 240 140 — 1 or 2 UL, FM
87-120099-600* 2 12 Momentary 360 240 140 — 1 or 2 UL, FM
897494-000 1.5 14.2 Steady 380 240 150 — 1 UL, FM
897494-530 1.5 14.2 Steady 380 240 150 — 1 UL, FM
90-487100-001* 2 12 Momentary 360 240 140 —— 1 or 2 UL, FM
FM Group A 0.458 52 Steady 1440 760 480 340 1 FM
FM Group B, D 0.7 34 Steady 940 500 300 220 1 FM
FM Group E, G 0.42 57 Steady 1570 760 525 370 1 FM
FM Group F Skinner 24 Vdc, 22 Watt Solenoid 7312BN4TNLVNOC322C2 1 FM
FM Group I Victaulic 24 Vdc, 8.7 Watts, 364 mA series 753-E Solenoid 1 FM
FM Group J Viking Model No. 11591, 11592, 11595, and 11596, 24 Vdc, 10 Watts 1 FM
FM Group K Viking Model No. 11601, 11602, and 13215, 24 Vdc, 9 Watts 1 FM
Device
I (Min.)
Amps
Resistance
(Max.) Ohms
On Time
Max. Number
per Circuits
Agency
83-131025-001 * 3 Momentary 1
Table B-4. Miscellaneous Devices
Device Model Number Supplier/Mfg.
Receiving Units for Central Station 5104B Silent Knight
