Kidde AEGIS 84-732001-001

Installation
P/N 06-236716-001 2-15 August 2007
2-4.2 Input Circuit Wiring (TB1 through TB7)
Refer to Appendix B for a list of compatible listed smoke/electronic heat detectors.
Figure 2-13A. Class B, Style B Wiring for Smoke/Electronic Heat Detectors
Figure 2-13 B. Class A, Style D Wiring for Smoke/Electronic Heat Detectors
1+
1-
2-
2+
EOL RESISTOR
5.1K, 0.5 W
P/N 06-129025-002
7
6
3
2
1
7
6
3
2
1
TB1, TB2, TB3
1+
1-
2-
2+
EOL RESISTOR
5.1K, 0.5 W
P/N 06-129025-002
7
6
3
2
1
7
6
3
2
1
TB1, TB2, TB3
