Technical Specifications
P/N 06-236716-001 C-1 August 2007
APPENDIX C
TECHNICAL SPECIFICATIONS
Item Description
ANUMBER OF HAZARDS One (1)
BPOWER
AC Main Input 120 Vac/240 Vac 50/60 Hz (90 to 264 Vrms, 47 to 63 Hz)
Current Consumption
120 Vac:
240 Vac:
3.2 Amps
1.6 Amps
Required Breaker 15 Amps
Power Supply Output 5.4 Amps @ 27 Vdc
Battery Charger Output 6 Amps @ 27 Vdc
Battery Capacity Up to 68 AH @ 24 Vdc
Battery Cutout Voltage 18.6 Vdc
Auxiliary Power Output 1 Amp maximum @ 24 Vdc Nominal
Battery Transfer 85% of 120 Vac
85% of 240 Vac
C Input Circuits
C.1 Detection Circuits Three (3)
- Two (2) for Suppression Input
- Third configurable as either independent Detection Circuit or
for Waterflow
Compatible Devices - 25 conventional electronic Smoke/Heat detectors listed in
Appendix B.
- A quantity of Normally-Open contact-closure devices subject
to maximum allowable wiring resistance.
Circuit Type - Class A (Style D) or Class B (Style B) supervised
- Detects Opens and Ground Faults
- Power Limited
Circuit Voltage Nominal 24 Vdc, 28 Vdc maximum
Maximum Line Resistance 100 ohms per loop
Maximum Alarm Current 70 mA
End-of-Line Resistor 5.1K, 5%, 1/2 W
