Kidde AEGIS 84-732001-001

Installation
P/N 06-236716-001 2-19 August 2007
Figure 2-15C. Agent Release Circuit — Dual Solenoid, Power-Limited
Figure 2-15D. Agent Release Circuit — Dual Solenoid, Non-Power-Limited
BLK
RED
IN-LINE RELEASING DEVICES
P/N 06-220023-001
MUST BE INSTALLED CLOSE
NIPPLED TO SOLENOID ENCLOSURES
TB14 OR TB15
R1+
R1-
R2-
R2+
BLK
RED
SOLENOID
TB14 OR TB15
R1+
R1-
R2-
R2+
SOLENOID
