Configuration
P/N 06-236716-001 3-11 August 2007
34 NAC 3 Pre-Release
(see note 9)
0 — 60 bpm Non-Silenceable
1 — 60 bpm Silenceable
2 — 120 bpm Non-Silenceable
3 — 120 bpm Silenceable
4 — Steady Non-Silenceable
5 — Steady Silenceable
6 — Temporal Non-Silenceable
7 — Temporal Silenceable
8 — Intelligent Synchronization - Non-Silenceable
9 — Intelligent Synchronization - Silenceable (Horn &
Strobe)
A — Intelligent Synchronization - Silenceable (Horn Off)
C — NAC 3 Off (see note 7)
3
35 NAC 3 Releasing
(see note 10)
0 — 60 bpm Non-Silenceable
1 — 60 bpm Silenceable
2 — 120 bpm Non-Silenceable
3 — 120 bpm Silenceable
4 — Steady Non-Silenceable
5 — Steady Silenceable
6 — Temporal Non-Silenceable
7 — Temporal Silenceable
8 — Intelligent Synchronization - Non-Silenceable
9 — Intelligent Synchronization - Silenceable (Horn &
Strobe)
A — Intelligent Synchronization - Silenceable (Horn Off)
C — NAC 3 Off (see note 7)
5
36 NACs Used for
General Alarm
1 — NAC #1
2 — NAC #2
3 — NAC #1 & NAC #2
4 — NAC #3
5 — NAC #1 and NAC #3
6 — NAC #2 & NAC #3
7 — NAC #1 & NAC #2 & NAC #3
8 — None (No General Alarm)
8
Table 3-1. Configuration Settings
Configuration
Number
(Position 1, 2)
Configuration Item Configuration (Position 3) Selection
Default
Mode
