Configuration
P/N 06-236716-001 3-13 August 2007
NOTES:
1. If "circuit not used" is selected, do NOT install an EOL as the control unit needs to see open
circuit. Using an EOL will cause trouble.
2. DET 1, DET 2, and DET 3/WF will activate first alarm ONLY IF it is part of the ARC activation
condition.
3. SUPV 1 will activate first alarm ONLY IF it is part of the ARC activation condition.
4. If Initiator is selected for any Release circuit output, the respective Power-Limited switch setting
is ignored.
5. The NAC will be driven by both ARC 1 and ARC 2. However the first ARC to reach each state is
given precedence. Once its cycle is complete, the other ARC, if active, will gain control.
6. The NAC may be related to neither ARC if the control unit is used for non-suppression
applications. Also see notes 8 to 10.
7. An OFF condition is different from NOT USED and will require that an EOL be installed.
8. In addition to being selectable for NACx First Alarm, the various tones are also selectable in the
condition that both ARCs are not used and one of DET 1, DET 2 or DET 3/WF is in alarm.
9. In addition to being selectable for NACx Pre-Release, the various tones are also selectable in the
condition that both ARCs are not used and two of DET 1, DET 2 or DET 3/WF are in alarm.
10. In addition to being selectable for NACx Releasing, the various tones are also selectable in the
condition that both ARCs are not used and all of DET 1, DET 2 and DET 3/WF are in alarm.
39 NAC #3 General Alarm 0 — 60 bpm Non-Silenceable
1 — 60 bpm Silenceable
2 — 120 bpm Non-Silenceable
3 — 120 bpm Silenceable
4 — Steady Non-Silenceable
5 — Steady Silenceable
6 — Temporal Non-Silenceable
7 — Temporal Silenceable
8 — Intelligent Synchronization - Non-Silenceable
9 — Intelligent Synchronization - Silenceable (Horn &
Strobe)
A — Intelligent Synchronization - Silenceable (Horn Off)
C — NAC 3 Off (see note 7)
7
Table 3-1. Configuration Settings
Configuration
Number
(Position 1, 2)
Configuration Item Configuration (Position 3) Selection
Default
Mode
