Technical Specifications
August 2007 C-4 P/N 06-236716-001
EENCLOSURE
Degree of Protection NEMA 1
Material of Construction 18 Gauge (0.053 inches or 1.35 mm) sheet steel
Color Red
Assembled Dimensions
- With Standard Door
- With Switch-Door
14-1/4 in. Width x 5 in. Depth x 19 in. Height
(362 mm x 127 mm x 483 mm)
14-1/4 in. Width x 6 in. Depth x 19 in. Height
(362 mm x 152 mm x 483 mm)
Approximate Weight (without
batteries)
- Standard Assembled
- Standard Shipping
- Canadian Assembled with
Dead-Front Panel
- Dead Front Panel Shipping
- Switch Panel Assembled
- Switch Panel Shipping
18 lbs. (8 kg)
21 lbs. (9 kg)
22 lbs. (10 kg)
4 lbs. (2 kg)
19 lbs. (8 kg)
21 lbs. (10 kg)
F OPERATING ENVIRONMENT
Temperature 32°F to 120°F (0°C to 49°C)
Relative Humidity
93% RH @ 90
°F
Item Description
