Appendix One:Selection Table for Brake Resistor
Driver Model
Driver
Power[W]
Brake Resistor[Ω ]
Brake
Resistor
Model(Ref.)
Brake
Resistor
Power[W]
（Ref.）
Brake
Resistor
Withstand
Voltage[VDC]
（Min.）
Min.
Max.
Ref.
CD420-0020-0016-AA-000
200W
32
100
75
T-75R-100
100
500
CD420-0040-0031-AA-000
400W
32
100
75
100
500
CD420-0075-0039-AA-000
750W
32
80
75
100
500
CD430-0100-0063-AA-000
1000W
24
48
39
T-39R-200
200
500
CD430-0105-0054-AA-000
1.05KW
24
48
39
200
500
CD430-0125-0065-AA-000
1.25KW
20
40
39
200
500
CD430-0126-0062-AA-000
1.26KW
20
40
39
200
500
CD620-0126-0043-AA-000
1.26KW
50
120
75
T-75R-200
200
800
CD620-0157-0054-AA-000
1.57KW
50
100
75
200
800
CD620-0188-0062-AA-000
1.88KW
40
80
75
200
800
Note:Please set brake resistor value and power in d5.04 and d5.05 when using brake resistor.
Please select brake resistor power according to real application.
Appendix Two:Selection Table for Fuse
Driver Model
Driver Power[W]
Specification
CD420-0020-0016-AA-000
200W
3.5A/250VAC
CD420-0040-0031-AA-000
400W
7A/250VAC
CD420-0075-0039-AA-000
750W
15A/250VAC
CD430-0100-0063-AA-000
1000W
20A/250VAC
CD430-0105-0054-AA-000
1.05KW
20A/250VAC
CD430-0125-0065-AA-000
1.25KW
25A/250VAC
CD430-0126-0062-AA-000
1.26KW
25A/250VAC
CD620-0126-0043-AA-000
1.26KW
15A/500VAC
CD620-0157-0054-AA-000
1.57KW
16A/500VAC
CD620-0188-0062-AA-000
1.88KW
20A/500VAC
