Kinco CD430 - Chapter 6 Operation on Input;Output Ports; Digital Input Signals; Polarity Control on Digital Input Signals

35
d5.08
25010210
ADC_Shift_V
Indicates data configuration of V phase shift
Note:Factory parameters
N/A
d5.09
30000110
Voltage_200
ADC original data when DC bus voltage is 200 V
Note:Factory parameters
N/A
d5.10
30000210
Voltage_360
ADC original data when DC bus voltage is 360 V
Note:Factory parameters
N/A
d5.11
60F60610
Comm_Shift_UVW
Indicates the excitation pointer of a motor
Note:Factory parameters
N/A
d5.12
26000010
Error_Mask
Indicates error masks
Note:Factory parameters
FFF.F
d5.13
60F70510
RELAY_Time
Indicates the relay operating time of capacitor
short-circuits
Unit: mS
Note:Factory parameters
150
d5.14
2FF00408
Key_Address_F001
Sets numeric display data
N/A
Chapter 6 Operation on Input/Output Ports
KINCO CD servo driver has 7 digital input ports (a digital input port can receive high-level or low-level
signals, depending on whether high-level or low-level signals are chosen at the COM terminal) and 5 digital
output ports (the OUT1-OUT4 ports can drive 100 mA load, and OUT5 port can drive 800 mA load, and can
directly drive the internal contracting brake device). You can freely configure all functions on digital
input/output ports according to application requirements.
6.1 Digital Input Signals
6.1.1 Polarity Control on Digital Input Signals
Table 6-1: Simplified IO polarity setting variables
Numeric
Display
Variable Name
Meaning
Default Value
Range
d3.08
Dio_Polarity
Sets IO polarity
0
N/A
