Kinco CD430 - Motor Selection, Trial Operation and Parameter List; Driver and motor configuration

30
Parameter List: Group F003 (To Set Input/Output & Pattern Operation
Parameters)
Numeric
Display
Internal
Address
Variable Name
Meaning
Default
Value
Range
d3.00
2FF00108
Store_Loop_Data
1: Stores all setup parameters except
motors
10: Initializes all setup parameters except
motors
0
N/A
d3.01
20100310
Din1_Function
000.1: Driver enable
000.2: Driver fault reset
000.4: Operation mode control
000.8: P control for velocity loop
001.0: Position positive limit
002.0: Position negative limit
004.0: Homing signal
008.0: Reverse speed demand
010.0: Internal speed control 0
020.0: Internal speed control 1
040.0: Internal position control 0
080.0: Internal position control 1
100.0: Quick stop
000.1
N/A
d3.02
20100410
Din2_Function
000.2
N/A
d3.03
20100510
Din3_Function
000.4
N/A
d3.04
20100610
Din4_Function
000.8
N/A
d3.05
20100710
Din5_Function
001.0
N/A
d3.06
20100810
Din6_Function
002.0
N/A
d3.07
20100910
Din7_Function
004.0
N/A
d3.08
20100110
Dio_Polarity
Sets IO polarity
0
N/A
d3.09
2FF00810
Dio_Simulate
Simulates input signals, and enforce
output signals for outputting
0
N/A
d3.10
20000008
Switch_On_Auto
Automatically locks motors when drivers
are powered on
0: No control
1: Automatically locks motors when drivers
are powered on
0
N/A
d3.11
20100F10
Dout1_Function
000.1: Ready
000.2: Error
000.4: Position reached
000.8: Zero velocity
001.0: Motor brake
002.0:Velocity reached
004.0: Index
008.0: The maximum speed obtained in
the torque mode
010.0: PWM ON
000.1
N/A
d3.12
20101010
Dout2_Function
000.2
N/A
d3.13
20101110
Dout3_Function
00a.4
N/A
d3.14
20101210
Dout4_Function
000.8
N/A
d3.15
20101310
Dout5_Function
001.0
N/A
d3.16
20200D08
Din_Mode0
If a digital input is defined as Operation
mode control,then this operation mode is
selected when the input signal is invalid
-4
N/A
