Kinco CD430 - Example 7-8: Analog - Torque Mode (Setting the Dead Zone Voltage and Offset Voltage)

67
d3.30
Analog_Torque_Con
Selects analog - torque
channels
0: Invalid analog
channel
1: Valid analog channel
1 (AIN1)
2: Valid analog channel
2 (AIN2)
Valid mode 4
Set to 2
d3.00
Store_Loop_Data
1: Storing all
configured parameters
for the control loop
10: Initializing all
parameters for the
control loop
Set to 1
Example 7-8: Analog – torque mode (setting the dead zone voltage and
offset voltage)
Requirement: The offset voltage is 1V, and the dead zone voltage is 0.5V. The motor Kt is 0.48 Nm/A, and the
peak current of the driver is 15A. The analog input voltage 10V corresponds to 0.64Nm. Select analog
channel 2 (AIN2) to control the torque.
Fig. 7-13 Schematic diagram of Example 7-8
Calculate
filter
U
according to the offset voltage and dead zone voltage that require settings:
2047
10 10
filter
shift dead
U
v v U U


(In this example,
0
dead
U 
.5, and
1
shift
U 
)
Result:
filter
U
=1740
Calculate
demand
I
according to the required torque
demand
T
:
*2
demand
demand
t
T
I
K

