OUT5+
Digital output
interface 5+
Maximum output current: 800 mA
OUT5-
Digital output
interface 5-
X2
CD420
U/V/W/PE
Power cable interface of a motor
L/N
Main power interface (single-phase 220 VAC)
RB+/RB-
Braking resistor interface
CD430
CD620
U/V/W/PE
Power cable interface of a motor
X3
CD420
CD430
CD620
ENCODER OUT
Signal output interface of a motor encoder
RS232
RS232 interface that communicates with a host PC or
controller
X4
CD420
CD430
CD620
ENCODER IN
Encoder interface of a motor
X5
CD430
CD620
R/S/T
Main power interface (single-phase or three-phase AC 220V
for CD430 and three-phase AC 380 V for CD620)
RB+/RB-
Braking resistor interface
DC+/DC-
DC bus interface
-----
CD420
CD430
CD620
SHIELD
Fixed terminal for the shielded wires of motor cables
