RX6030 / RX7030 / RX8030



(1) Turn Signal Lamp (RR)

1. The turn signal lamp(rear) is in-

stalled on the rear fender.

M55O7A1A

2. Unscrew the mounting bolts from

the inside of the rear fender.

(1) Protective Cover

(2) Mounting Bolt

T11O746A

(1) Turn Signal Lamp (RR) Bulb

3. Remove the bulb by turning its

socket counterclockwise. Install a

new bulb.

M55O7A3A

TF120(RX6030,7030,8030)-AU-07.in44 44 2016-06-17 오후 1:55:55
