Klafs 21033 - Vent Flap for Airing and Ventilating the Cabin (Optional)

90 °C
60 °C
40 °C
Page 77 / 96
10.12. Vent flap for airing and ventilating the cabin (optional)
Correct airing and ventilation ensure an optimum climate.
The KLAFS vent wall with adjustable vent flap (optional) allows you to regulate the air flow rate.
1
4
Level
Ventilation: Heating mode
Vent flap, level 1
There is only a low air flow at this setting.
Ventilation: Sauna mode
Vent flap, level 4
Session with maximum number of users.
There is maximum air flow at this setting.
The higher the air flow rate, the better the
sauna climate. Intermediate levels can be
selected depending on the number of users.
However, you must distinguish between
Sauna, SANARIUM or InfraPLUS (optional)
mode.
Sauna:
Vent flap, level 4 to 3.
SANARIUM:
Vent flap, level 1 to 2.
InfraPLUS:
Vent flap, level 1 to 2.
Set the vent flap to level 4 during final drying.
