Software update
Updating the software entails risks and should therefore only be carried out using these instructions
and by trained staff. Faulty updating can destroy the lift controller. Therefore, you must carefully read
the sections below.
Requirements
The following points must be fulfilled to be able to carry out a software update:
❑ micro-SD card available
❑ software available (GENIUS_SW_V1_002B.DMP)
❑ PC, notebook or netbook available to copy new files
Update steps (overview)
The update steps are explained in chronological order in the following. They are imperative to avoid a
faulty software update.
❑ Copy the new software (GENIUS_SW_V1_002B.DMP) to the micro-SD card
❑ Insert the micro-SD card into the controller
❑ Enter 691, confirm with OK (all current data are stored)
❑ In this way the current software, parameters, settings are backed up in a SAVE folder on
the micro-SD card
❑ Enter 698xxx (e.g. 698000) and confirm with OK -> updates the software using the
GENIUS_SW_V1_002B.DMP file in the root directory of the card
Updating the software
Preparation
If the controller is already in operation, put it out of operation first. Make sure that the car is empty
and change the operating mode. There are several possibilities:
❑ Recall mode - by enabling the recall switch in the control cabinet
❑ Out-of-order mode - by turning off the master switch
It must be ensured in any case that the car cannot move due to landing or car calls, as this would
disturb or even render the updating procedure impossible. Disabling the landing control is not
sufficient.
Now insert the micro-SD card - if required with adapter - into your PC, netbook or similar. It is
recognised as mass storage device. Then copy the supplied software GENIUS_SW_V1_002B.DMP into
the root directory of the micro-SD card. Remove the card and insert it into the controller.
Carrying out the update
In the status overview, open the input keyboard by clicking the CMD button. Now the screen should
be as follows:
Restart the controller using the 6060 → OK commands. Enable the CMD menu again after the restart
and open the input menu.
