Kleemann GENIUS20 User Manual

41
MA06-03-1-01
Menu
[Direct access: CMD -> 7102]
Parameter
[Direct access]
Description
Default
value
Value Range
Arrival Gong
"YES" serves to send the gong signal on the
bus, if e.g. a landing has been approached.
YES
YES/NO
Only for landing call
When selecting „YES“, a gong signal in the
landing will only be issued when the
landing was approached due to a landing
call.
Gong distance (mm)
Definition of the distance from which the
signal referring to the next approached
landing is to be given.
500
0-9999
On going direction
gong
Defines whether an on going direction
gong is to be put out.
NO
YES/NO
Gong on door1 open
Defines whether a gong is to be put out
when the door1 opens.
NO
YES/NO
Gong on door2 open
Defines whether a gong is to be put out
when the door2 opens.
NO
YES/NO
Speech on bus
"YES" serves to activate a voice output
which is connected to the bus. The voice
output thereupon plays texts for landing
and status information.
YES
YES/NO
Speech distance(mm)
Definition of the distance from which the
voice output for the next approached
landing is to be given.
500
0-9999
Speech on
direction
"YES" serves to activate a voice output,
which is connected to the bus, at the start
of the travel, according to the direction of
the travel. In this case, text no.76 is the
voice output for upwards movement and
text no.77 for downwards movement.
NO
YES/NO
