Menu
Parameter
[Direct access]
Description
Default value
Value
Range
O:Door open
signal
Definition of the output for the door opening
signal.
C.49.8 (door 1)
C.50.8 (door 2)
O:Door close
signal
Definition of the output for the door closing
signal.
C.49.7 (door 1)
C.50.7 (door 2)
O:Nudging
Definition of an output which serves to provide
the door controller with the signal for slow
forced closing, given the “nudging signal” is
active.
O: Additional
retiring cam
Definition of the output for the activation of
the retiring cam (when there is a VVVF door
and a retiring cam).
t: Delay On (ms)
Time delay from the activation of the
additional retiring cam until the door opening.
1500
0-5000 ms
t: Delay Off (ms)
Time delay in milliseconds for the retiring cam
deactivation during door opening.
1500
0-5000 ms
O: Door is fully
open
Definition of the output for the signal
indicating that the door is fully open.
O: Door open due
to LC
Definition of an output for the signal that the
door cannot be closed due to an interruption
of the light curtain.
The parameters of the submenu “Door signals DS2” are exactly the same with the ones for the 1st
door.
