Kleemann GENIUS20 User Manual

88
MA06-03-1-01
Menu
Parameter
[Direct access]
Description
Default
value
Value Range
I: MAX-Maximum
pressure
Definition of an input to monitor the
maximum pressure sensor.
I: Machine room temp.
Definition of an input to monitor the machine
room temperature.
I:MAI-maintenance
Definition of an input for maintenance.
I:Certification switch
Definition of an input for the certification
switch.
I:Min. room tempera.
Definition of an input for minimum room
temperature.
1I:Building services
Definition of the 1. input for the building
services; 8 successional I/Os are being
assigned. With these inputs it is possible to
transmit 8 different status signals.
I:Over temperature
OT1
Definition of an input to monitor over
temperature 1.
Over temperature is controlled for all normal
travels as well as for inspection runs.
I:Over temperature
OT2
Definition of an input to monitor over
temperature 2.
I:Over temperature
OT3
Definition of an input to monitor over
temperature 3.
I:Over temp.(DM1)
DT1
Definition of an input to monitor over
temperature 4 (door 1 motor thermistor).
I:Over temp.(DM2)
DT2
Definition of an input to monitor over
temperature 5 (door 2 motor thermistor).
I:Shaft light on/off
Definition of an input for an extra shaft light
switch.
I:Temperature run
Definition of an input for temperature travel.
Especially in the case of glass elevators, it can
happen that the air in the lift strongly heats up
when there is strong sunlight. In this case,
travel between the upper and lower floors can
be triggered via the entry "Temperature
travel", in order to achieve some air exchange.
I:Inspection fast
Definition of an input for the fast button of the
inspection bulb if the standard input at
KMCTB is not used.
I:L4-Control
This parameter defines the input for
moniroting the light voltage if the monitoring
