Kleemann GENIUS20 User Manual

93
MA06-03-1-01
Menu
Parameter
[Direct access]
Description
Default
value
Value
Range
O: Shaft VU
Determination of an output to signal that the
lower prefinal switch is activated.
O:v > limit
Determination of an output to signal that the
speed is currently exceeding the rated speed.
O:v > 0.3 m/s
The output is activated if the current speed
exceeds 0.3 m/s.
O:Speed Vn
The output is activated when the rated speed is
reached.
O:In order
Determination of an output to signal normal
operation.
O:Safety brake
Definition of an output which activates a safety
brake in rope traction lifts with
gear when the inverter does not supply
appropriate outputs/contacts (e.g. inverter with
integrated main contactors.)
t:delay(ms)
Definition of the delay time for the safety brake.
The delayed initiation of the safety brake is
meant to reduce noise emission.
O:Reset inverter
Definition of an output for restarting the
frequency inverter.
O:Shaft light on/off
Definition of an output to switch the shaft light,
e.g. using a relay. During the switching
procedure, a pulse length of approx. 500 ms is
applied.
O:Car is in safe zone
Definition of an output for reporting “Zone”. The
message is issued when the car is located within
the zone and the signal transmitter-centre has
responded.
O:Deceleration point
Determination of an output to signal the
deceleration point when switching from rated
speed to a slower velocity.
O:v0 offpoint
Determination of an output to signal that speed
v0 is decreasing.
