SECTION 4
MAINTENANCE
Jan 2002
Page 4-8
05114590
SL-IV SERVICE LOG – PARTS REFERENCE LIST
Ref.
No.
Part No.
(CCN)
4.3.1 PART DESCRIPTION
1 10106722 Filter Element, Low Pressure Water, 2 each x 10 microns
2 05049698 Filter Element, Hydraulic Oil
3 Filter Element, High Pressure Water, ¼ HP, 3/8 HP, or 9/16 HP
4 05022702 Hydraulic Oil Change
5 05112487 Seal, HP Plunger (StreamLIFE)
6 10110393 Seal, HP Discharge (Sealing Head)
7 05009030 Seal, Hydraulic, Plunger Cartridge
8 05108113 Plunger, Ceramic
9 05109624 Liner, HP Cylinder
10 05059712 Cylinder, HP
11 10086288 Ball, HP Check Valve
12 10107902 Seat, HP Check Valve (Wear out first side, then reverse and use opposite side)
13 10107902 Seat, HP Check Valve (Wear out second side, then replace)
14 05022017 Spring, HP Check Valve
15 05012331 Guide Sleeve, HP Check Valve
16 10107894 Poppet, LP Water Inlet Check Valve (Wear out first side, then reverse to use opposite side)
17 10107894 Poppet, LP Water Inlet Check Valve (Wear out second side, then replace poppet)
18 49884562 Spring, Poppet LP Inlet Check Valve
19 05049853 O-ring, LP Inlet Check Valve
20 49865843 Stem, HP Dump Valve
21 10178978 Seal Assy, HP Dump Valve
22 10178697 Seat, Replaceable, HP Dump Valve
