18
Figure 3-1 Dimensions in mm
3. Description
3.3 Functional description
The grinding and polishing machine can be used to automatically sharpen, deburr and polish
linear and convex flat cutter knives in knife size of maximum 700 x 550 mm.
The knife is fastened onto a copy clamping plate and is moved along the wet grinding belt or the
flap brushes in movements that follow the shape of the knife.
Grinding angles between 5° and 35° can be steplessly adjusted on the grinding unit.
In case of emergency, the grinding and polishing machine can immediately be stopped by
pressing the “Emergency Stop” button.
GoCGoC
approx. 1500 mm approx. 1500 mm
approx. 1800 mm
