7. Operation
Figure 7-9 Aligning the left polishing unit
Figure 7-10 Aligning the left polishing unit
Wrong Wrong Right
1
Figure 7-8 Main screen
7.3.5 Aligning the left polishing unit
As the upper and lower brushes of the left polish-
ing unit wear off with different levels of abrasion
over time, the position of the polishing unit must
be realigned at regular intervals.
Swivel the left polishing unit towards the knife
with the “Left Polishing Forward / Backward” (7-
8/1) button in the manual functions on the touch
panel.
Use the hand wheel to adjust the height (3-2/3) of
the “Left Polishing Unit” (3-3/2) so that the knife
edge is at the point of intersection of the flap
brushes.
ATTENTION
The height of the polishing unit on the left
must be adjusted so that the point of inter-
section of the flap brushes lies on the knife
edge.
