9.2.1 Cleaning of sub-structure

The guard plate (9-7/1) can be dismantled for

cleaning and servicing the sub-structure.

First, open the rear doors (3-2/4) on the backside

of the machine and pull out the connector plug

underneath the guard plate.

Then turn the Allen screws (9-7/2) all the way to

the stop in counter-clockwise direction from the

front. To do that, use a SW10 Allen wrench.

The guard plate can now be pulled forward and

out of the machine.

Re-assemble the guard plate in reverse sequence.

ATTENTION

Be careful while re-assembling the guard

plate as the limit switch and cable could be

damaged otherwise.

Flap brushes must not get wet, since they

can only absorb polishing paste and can only

correctly deburr a knife in dry state.

9. Care and maintenance

Figure 9-7 Dismantling the guard plate
